SMT PANASONIC FEEDER MV2F 1023035500 – 24×12mm K‑Type High‑Speed Tape Feeder
Reliable MV2F feeder for stable, precise delivery of 24 mm×12 mm SMD components.
Designed for reliable, high-speed SMT production, the 24×12 mm MV2F feeder ensures accurate component delivery with minimal misfeeds. The robust ratchet structure is engineered for long-term operation, supporting efficient assembly of mid-sized SMD components. Fully compatible with Panasonic MV2F, MV2VB, and MV2C platforms, this feeder enhances line uptime and placement precision in demanding manufacturing environments .
5.0
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Product Introduction
Designed for reliable, high-speed SMT production, the 24×12 mm MV2F feeder ensures accurate component delivery with minimal misfeeds. The robust ratchet structure is engineered for long-term operation, supporting efficient assembly of mid-sized SMD components. Fully compatible with Panasonic MV2F, MV2VB, and MV2C platforms, this feeder enhances line uptime and placement precision in demanding manufacturing environments .
Product Display
1023035500 MV2F 大T 24-12 飞达(13)
1022435700 MV2F 大T24-16飞达 (19)
1023035500 MV2F 大T 24-12 飞达(12)
微信图片_20250611183037
微信图片_20250611183033
微信图片_20250611183009
微信图片_20250602141849
微信图片_20250530094504
微信图片_20250524144724
Product Advantages
Accurate and Stable Feeding: Ensures precise component delivery to the pick-up point, minimizing misfeeds and errors.
Durable Construction: Built with high-strength materials for long service life and reliable performance in continuous production.
Easy Maintenance: Quick tape loading and simplified upkeep reduce downtime and boost line efficiency.
Application Scenario
Consumer electronics
Smartphone motherboards, TWS earphone circuit boards, smartwatch modules
Automotive electronics
ECU control board, vehicle-mounted sensors, charging modules for new energy vehicles
LED display
Mini LED backlight module, outdoor display screen unit
Medical electronics
PCBs for medical imaging equipment, implantable sensors
FAQ
1
What is the typical lifespan of an SMT Feeder? How to extend its service life?
Standard lifespan: The average lifespan of an industrial-grade SMT Feeder is 3 to 5 million cycles. For example, the Yamaha CL series can reach up to 8 million cycles.
2
How to fix communication errors between SMT Feeder and pick-and-place machine?
Confirm that the PIN pins of the Feeder interface are not bent or oxidized. Check whether the Feeder firmware version supports the model of the chip mounter. Restart the control unit of the chip mounter and reload the parameter configuration file of the Feeder.
3
Can third-party SMT Feeders match OEM performance?
Third-party Feeders have an advantage in terms of short-term costs, but there are significant differences. For high-precision and large-batch production, it is preferable to choose the original factory feeders. For trial production or scenarios with low complexity, it is possible to try high-quality third-party brands.
4
How to quickly replace worn parts like feeder gears?
Cut off the power supply and remove the tape.
Use a 3mm hexagonal wrench to remove the gear cover plate (pay attention to the spring tension).
Take out the old gear set and compare the pitch consistency with that of the new gear.
Apply thermal conductive silicone grease and then install the new gear.
Use a calibration jig to test the feeding tension (target value: 2.5N±0.3N).
5
Can you customize SMT Feeders for non-standard tape widths?
YES
