SMT Mirae Feeder 82MM | Legacy 1st-Gen C-Type Feeder with Tail for Mirae Machines
First-generation 82MM C-Type Feeder with tail – For legacy Mirae SMT equipment
This legacy 1st-generation SMT Mirae C-Type Feeder (82MM with tail) is engineered for precise feeding of wide-tape components in older Mirae SMT platforms. The “tail” design enhances tape stability and ensures smoother feeding, especially for bulky components or those in larger packaging formats. Built for durability and consistent performance, it’s a reliable option for extending the life and productivity of legacy SMT production lines.
5.0
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Product Introduction
This legacy 1st-generation SMT Mirae C-Type Feeder (82MM with tail) is engineered for precise feeding of wide-tape components in older Mirae SMT platforms. The “tail” design enhances tape stability and ensures smoother feeding, especially for bulky components or those in larger packaging formats. Built for durability and consistent performance, it’s a reliable option for extending the life and productivity of legacy SMT production lines.
Product Display
1 (10) (3)
1 (12) (3)
1 (2) (15)
微信图片_20211209171141
微信图片_20211209171239
微信图片_20211209171243
微信图片_20211209171247
微信图片_20211209171251
微信图片_20220614173514
Product Advantages
Accurate and Stable Feeding: Ensures precise component delivery to the pick-up point, minimizing misfeeds and errors.
Durable Construction: Built with high-strength materials for long service life and reliable performance in continuous production.
Easy Maintenance: Quick tape loading and simplified upkeep reduce downtime and boost line efficiency.
Application Scenario
Consumer electronics
Smartphone motherboards, TWS earphone circuit boards, smartwatch modules
Automotive electronics
ECU control board, vehicle-mounted sensors, charging modules for new energy vehicles
LED display
Mini LED backlight module, outdoor display screen unit
Medical electronics
PCBs for medical imaging equipment, implantable sensors
FAQ
1
What is the typical lifespan of an SMT Feeder? How to extend its service life?
Standard lifespan: The average lifespan of an industrial-grade SMT Feeder is 3 to 5 million cycles. For example, the Yamaha CL series can reach up to 8 million cycles.
2
How to fix communication errors between SMT Feeder and pick-and-place machine?
Confirm that the PIN pins of the Feeder interface are not bent or oxidized. Check whether the Feeder firmware version supports the model of the chip mounter. Restart the control unit of the chip mounter and reload the parameter configuration file of the Feeder.
3
Can third-party SMT Feeders match OEM performance?
Third-party Feeders have an advantage in terms of short-term costs, but there are significant differences. For high-precision and large-batch production, it is preferable to choose the original factory feeders. For trial production or scenarios with low complexity, it is possible to try high-quality third-party brands.
4
How to quickly replace worn parts like feeder gears?
Cut off the power supply and remove the tape.
Use a 3mm hexagonal wrench to remove the gear cover plate (pay attention to the spring tension).
Take out the old gear set and compare the pitch consistency with that of the new gear.
Apply thermal conductive silicone grease and then install the new gear.
Use a calibration jig to test the feeding tension (target value: 2.5N±0.3N).
5
Can you customize SMT Feeders for non-standard tape widths?
YES
