SMT I-PULSE FEEDER LG4-M2A00-100 – F2-82MM 8×2mm Feeder for High-Speed Component Placement 1

SMT I-PULSE FEEDER LG4-M2A00-100 – F2-82MM 8×2mm Feeder for High-Speed Component Placement 2

SMT I-PULSE FEEDER LG4-M2A00-100 – F2-82MM 8×2mm Feeder for High-Speed Component Placement 3

SMT I-PULSE FEEDER LG4-M2A00-100 – F2-82MM 8×2mm Feeder for High-Speed Component Placement 4

SMT I-PULSE FEEDER LG4-M2A00-100 – F2-82MM 8×2mm Feeder for High-Speed Component Placement

I-PULSE LG4-M2A00-100 feeder delivers stable, precise tape feeding for 8mm SMD reels.

Engineered with durable materials and precise step-feeding mechanics, the LG4-M2A00-100 delivers stable and accurate component supply from 8mm tape reels. Compatible with I-PULSE M-series machines (M1, M2, M4, M6, M8), this feeder enhances placement reliability and efficiency in high-volume SMT lines.

Model: I-PULSE F2-82MM
Part Number: LG4-M2A00-100
Type: 8×2mm electric tape feeder
Compatible Machines: I-PULSE M1 / M2 / M4 / M6 / M8 series
Suitable Components: 1005, 0805, 0603 small SMD chips
Key Features:
- Precise and stable tape feeding
- Quick-change modular design
- Long service life for continuous operation
- Easy to operate and maintain

Inquiry

Write a Review

Product Introduction

Model: I-PULSE F2-82MM
Part Number: LG4-M2A00-100
Type: 8×2mm electric tape feeder
Compatible Machines: I-PULSE M1 / M2 / M4 / M6 / M8 series
Suitable Components: 1005, 0805, 0603 small SMD chips
Key Features:
- Precise and stable tape feeding
- Quick-change modular design
- Long service life for continuous operation
- Easy to operate and maintain

Product Display

微信图片_20231007093849

微信图片_20231007093551

微信图片_20231007093844

1 (240)

1_1

2 (103)

3 (77)

3_1

5 (20)

Product Advantages

SMT I-PULSE FEEDER LG4-M2A00-100 – F2-82MM 8×2mm Feeder for High-Speed Component Placement 16

Accurate and Stable Feeding: Ensures precise component delivery to the pick-up point, minimizing misfeeds and errors.

Durable Construction: Built with high-strength materials for long service life and reliable performance in continuous production.

Easy Maintenance: Quick tape loading and simplified upkeep reduce downtime and boost line efficiency.

Application Scenario

Consumer electronics

Smartphone motherboards, TWS earphone circuit boards, smartwatch modules

Automotive electronics

ECU control board, vehicle-mounted sensors, charging modules for new energy vehicles

LED display

Mini LED backlight module, outdoor display screen unit

Medical electronics

PCBs for medical imaging equipment, implantable sensors

FAQ

What is the typical lifespan of an SMT Feeder? How to extend its service life?

Standard lifespan: The average lifespan of an industrial-grade SMT Feeder is 3 to 5 million cycles. For example, the Yamaha CL series can reach up to 8 million cycles.

How to fix communication errors between SMT Feeder and pick-and-place machine?

Confirm that the PIN pins of the Feeder interface are not bent or oxidized. Check whether the Feeder firmware version supports the model of the chip mounter. Restart the control unit of the chip mounter and reload the parameter configuration file of the Feeder.

Can third-party SMT Feeders match OEM performance?

Third-party Feeders have an advantage in terms of short-term costs, but there are significant differences. For high-precision and large-batch production, it is preferable to choose the original factory feeders. For trial production or scenarios with low complexity, it is possible to try high-quality third-party brands.

How to quickly replace worn parts like feeder gears?

Cut off the power supply and remove the tape. Use a 3mm hexagonal wrench to remove the gear cover plate (pay attention to the spring tension). Take out the old gear set and compare the pitch consistency with that of the new gear. Apply thermal conductive silicone grease and then install the new gear. Use a calibration jig to test the feeding tension (target value: 2.5N±0.3N).

Can you customize SMT Feeders for non-standard tape widths?

YES
